CRT SS6900 Export version 7 + NRC
The latest version since JUNE 2022 CRT Superstar 6900 V 7 WITH NRC
Version 7 has a blue display, 240 channels and 40 watts on FM and 35 watts on SSB.
No more programming cable is needed to get on the regular 27 Mc channels.
You can manually open the new SS6900 version 7 + NRC cbradio to all bands.
Turn it on with the F and s/rf buttons pressed.
Then select 2 bands in the display via the channels button.
Then long press the F button.
The CRT SS6900 then resets itself.
Turn it off and on again, and it is open from 25.615 - 28.305.
Frequency range: FM: 25.615 - 30.105 MHz & USB/LSB: 25.615 - 28.305 MHz
Bands: AM / FM / LSB / USB / CW / PA
Transmit power: AM-CW 2-12Watt, FM 3-40Watt, USB / LSB 0-40Watt, SSB 10-40Watt (PEP)
Frequency steps: 10Hz / 100Hz / 1kHz / 10kHz
RF control
Noise blanker and ANL function
Programmable clarifier
S-Meter
Roger beep
Output power continuously adjustable (AM / FM)
Vox function
CTCSS Tones
DCS codes
RX Compander
Noise gate
RX Noise reduction
Scan function
Echo function
Dual Watch
Built-in SWR meter
Working voltage display
SWR protection in circuit
Input voltage overload protection
10kHz switch
Reset function
Time-out timer
Hi-cut function
Emergency channel
Key lock
Microphone type selection function: (electret or dynamic)
Programmable via PC (software and USB cable not included)
Connection for a programming cable on the backside
External speaker connection
PA speaker connection
PL-59 antenna connection
Power supply 13,8V DC
Dimensions in 280 x 250 x 60mm
Weight 2.1kg
WIRING OF MIC CABLE:
1 Common Ground
2 Mic Audio
3 PTT (connected to Pin 1 for TX)
4 +5V
Note 1: Never ground Pin-4, this will damage the radio.
Note 2: This wiring is not regular, common brands have a different wiring.
