TYT TH-8600 (IP67)
TYT TH-8600 (IP67)
16 Kenwood PMR CHANNELS version
General
Frequency Range(MHz):144-146MHz - 430-440 MHz (EXPORT 136-174/400-470)
Channel No.: 200
Frequency Stability: ±1ppm
Operating Temperature: -30℃～+60℃
Operating Voltage: 13.8V DC
Dimension: 107*125*45mm
IP67 Index
Transmitter
Output power: 25W
Transmitting Current: 4A@13.8V
Standby Current: 0.2A@13.8V
FM Modulation: Wide band:16K0F3E/ Narrow band:11 K0F3E
Modulation distortion: ＜5%
FM Hun and Noise: ≥45dB@25KHz / ≥40dB@12.5KHz
Adjacent Ch. Power: ≥60dB@12.5KHz / ≥70dB@25KHz
Audio response: +1~-3dB
Receiver
Sensibility: 0.2μV
Adjacent Ch. Selectivity: 60dB@12.5KHz / 70dB@25KHz
Intermodulation : ≥60dB/≥65dB
Spurious Rejection: ≥70dB
Audio response: +1~-3dB
RF Sensitivity: -122dbm(12db SINAD)
Audio Distortion : <5%
FM Hun and Noise: ≥45dB@25KHz /≥40dB@12.5KHz
Rated audio : 4W
